Barymat 5 - Mass Loaded Vinyl Barrier


Barymat 5 Barrier

Mass Loaded Vinyl Barrier Material

BARYMAT 5 is a thin, dense, plain noise barrier material available in 1.0 lb... and 2.0 lb... per sq... ft... weights (0.5 lb... also available). This flexible, mineral filled sheeting can be applied alone or in combination with other acoustic products where high transmission loss is required.


Also See: NoiseBlok

   Click here for Barymat 5 Technical Data Sheet - PDF Format
BARYMAT 5 is easy to apply and can be cut with common utility knives.

For secure and permanent installations use specified adhesive


APPLICATION AND PRODUCT DATA

Barymat 5
Performance data is an extract from NCR - Ottawa report on tests according to ASTM E 90-90.



Thickness

.07" thick, 5 B-0D: .14"

Standard Dimensions

Sheets: 54" wide X 72", untrimmed
Rolls: 54" wide X 40' rolls (5 B-0B only)
Custom trimming and die cutting can be provided


Typical Physical Properties:

Specific Gravity: 2.5

Colour: Black

Flammability: MVSS 302 - Passes

Weight: 5 B-0B: 1.0 lb.../sq.. ft.. 5 B-0D: 2.0 lb../sq. ft. (Also available 5 B-0E: 0.5 lb./sq.ft.)



Frequency
(Hz)
Absorption Coefficient
5 B-OB
5 B-OD
  80
17
22
  100
14
18
  125
13
18
  160
13
18
  200
14
19
  250
16
21
  315
17
22
  400
19
24
  500
20
25
  630
21
27
  800
22
28
  1000
24
30
  1250
26
32
  1600
28
34
  2000
29
36
  2500
31
37
  3150
34
40
  4000
35
42
  5000
36
43
  6300
36
44

  STC
24
30


   Click here for Barymat 5 Technical Data Sheet - PDF Format
MSDS Barymat 5
Click here for Barymat 5 MSDS - PDF Format
